Video walls shouldn’t be difficult to create. That’s why the BG-UHD-VW2X2 video wall processor requires almost no configuration. All users need to do is plug in their devices, select the layout, and adjust for bezel correction with three simple button presses. If needed, 180° output rotation is an option available for inverted displays to help with bezel obstructions.

These features combine to make this video wall processor a great industry-compliant device with no-fuss setup. With its ease of use, this video wall processor is a great and affordable choice for any application that would benefit from an eye-catching video wall display.

Connectivity

Simplicity is one of the BG-UHD-VW2X2’s greatest strengths. This video processor supports high resolution 4K @ 60Hz 4:4:4 input resolutions. The four HDMI outputs have a maximum resolution of 1080p @ 60Hz. This video processor is compliant with both HDCP 2.2 and HDMI 2.0. The device also supports loop out up to 4K @ 60Hz 4:4:4 for additional local display connectivity. For audio extraction, RCA and TOSLINK audio outputs are available.

Control

Operators have access to multiple control options for the BG-UHD-VW2X2, including an IR remote control, front panel buttons, and RS-232. On the IR remote, five preset bezel adjustments are available. Operators can also rotate the display 180° for inverted displays if needed. These configurations work for both commercial displays and for consumer-based TVs.

High Input Resolution:

Input up to 4K @ 60Hz 4:4:4

Alternate Layouts:

Choose From a Variety Of Video Wall Configurations

HDMI Loop-Out:

Additional Local Display Connectivity

Video Wall Processor:

Spread a Source Across Multiple Displays

Audio De-Embedding:

1 x RCA, 1 x TOSLINK

Multiple Control Options:

Front panel, IR Remote, RS232

• Configure for 1×1, 2×2, 1×2 (H), 1×3 (H), 1×4 (H), 2×1 (V), 3×1 (V), 4×1 (V) layouts
• Output up to 1080p @ 60Hz on each display
• 180 degrees output rotation for installations with inverted displays
• Supports AUX and Spdif audio extraction
• Plug and play unit
• Sturdy metal housing
• Edge shielding functions
• Mirror mode available (2×2 only)
• Compatible with HDCP 2.2
