BZBGEAR BG-EXH-150C 4K UHD HDMI HDBaseT Long Range Extender with Bi-directional IR/RS-232/CEC up to 490ft

SKU: BG-EXH-150C

$207.37

You need to extend HDMI signal and looking for reliable futureproof solution packed with all necessary features? Stop right there and search no more because you already found it – BZBGEAR BG-EXH-150C!

50 in stock

SKU: BG-EXH-150C Categories: , Brand:

Description

.whbthbgc img{max-width:450px!important}.ntcamwrap{max-width:1170px;margin:auto;}img{max-width:100%}.ncamdescr{max-width:1000px;margin:auto;line-height:30px!important;font-size:16px}.template2icimwr{width:100%;background-color:efefef;margin-top:50px}.template2icim{max-width:1140px;margin:auto;padding-top:50px;background-color:efefef}.template2icim1,.template2icim3{max-width:297px;width:100%;float:left;text-align:center;color:626262;font-size:18px;margin-bottom:30px}.picoht{min-height:225px!important}.template2icim1,.template2icim3{text-align:center;color:626262;font-size:18px}.picbrt{margin-top:14px;font-size:15px}.picoht img{max-width:95px!important;margin:auto}.nnfeat ul li{font-size:19px;list-style:none;padding:7px 0 10px 45px;color:585858;margin-left:10px;line-height:28px;background-size:26px auto!important;background:url(https://bzbexpress.com/img/icotp2sp.png) no-repeat left 8px top 8px;background-size:auto}.nnfeat{margin-top:45px;padding-bottom:45px}.nnfeatwrap2{padding-left:10px!important;padding-right:10px!important}.t2comptim img{max-width:230px!important;display:inline-block}.t2compth{margin-left:100px;font-size:24px;font-weight:700;margin-bottom:35px}.whbthbg{width:1190px;height:546px;background-image:url(https://bzbexpress.com/img/bgwht2.png);margin:auto}.idbuyt{font-weight:400!important;font-size:18px!important;margin-top:30px;line-height:32px}.fllt2{float:left;width:49%;margin-top:50px}.idbuyim{margin:0 30px 0 90px}.idbuyim,.idbuyc{float:left}.whbthbgc{margin-top:90px;margin-left:20px;text-align:center}.fllt2{float:left;width:49%;margin-top:80px}.idbuyc{font-weight:700;font-size:32px;margin-top:20px}.ttintwr p{font-weight:700;font-size:24px}.ttintwr{width:385px;min-height:175px;color:444446;text-align:left;line-height:22px}.ttintwr_l{margin-left:10px}.ttintwr_l,.ttintwr_r{display:inline-block;vertical-align:top}.ttintwrimg{float:left;margin-right:10px;width:160px;height:120px}.vd1{max-width:683px;margin:auto;border:1px solid ccc;max-height:380px}.tmopuntwr{margin:20px;background:f0f4f7;margin-top:50px;padding-top:30px;padding-bottom:30px;min-height:300px}.tmopuntwr img{display:inline-block;max-width:350px}.t2faqsb{margin-left:150px;line-height:40px;font-size:20px}
@media screen and (max-width: 1000px){
.whbthbgc img{display:none}.template2icim {display: none;}.picoht {min-height: 150px !important;}.template2icim1, .template2icim3 {width: 230px!important;margin-left:60px;margin-bottom: 0px;}.whbthbg {max-width: 98%!important;}.fllt2 {width: 95%!important;}.template2icim2{display:none}.t2compth{margin-left:15px!important}.t2faqsb{margin-left:15px!important}.nnfeatwrap2{padding-left:0!important}.idbuyim{margin:0 3px 0 15px !important}.ttintwr{width:inherit!important}.tmopuntwr img{display:inline-block;max-width:250px!important}.ntcamwrap{color:000!important}.t2comptim img{max-width:155px!important .ncamdescr {font-size: 16px!important;color:000!important}
}


You need to extend HDMI signal and looking for reliable futureproof solution packed with all necessary features? Stop right there and search no more because you already found it BZBGEAR BG-EXH-150C!

This device with a help of HDBaseT technology will extend HDMI signal for up to 150M (492 ft) with resolutions for up to 4K @ 60Hz using single CAT6 ethernet cable. But probably this is not the only feature you are looking for. So, it can do much more along with HDMI it will extend IR and RS-232 signal, so you can control your TV from the source side (for example, when using 3rd party control system) or you can control the source (like your cable box) from the TV side.

If you need to connect local audio system there is a 3.5mm mini-jack connector on the receiver which provides de-embedding audio from HDMI signal. If you need to duplicate transmitted signal there is a HDMI loop-out connector, which you can use to connect monitor or another device.

Power over category cable adds more convenience for your setup only one side (either transmitter or receiver) needs power adapter to be connected to electrical outlet, and to make it secure it has locking connector.

BZBGEAR BG-EXH-150C also supports many modern video technologies (like HDR, HDR10+, Dolby Vision and HLG) and audio formats as well as digital media protection for up to HDCP 2.2.

Extreme Range:

Transmit 1080p up to 492ft and 4K up to 394ft

HDR Support:

HDR, HDR10+, Dolby Vision, HLG

Multiple Types of Control:

Control devices with bi-directional IR, RS-232 and CEC pass-through

Stunning Image Quality:

Supports resolutions up to 4K @ 60Hz

PoC:

Only one of the units, TX or RX, needs to be plugged into AC power

Audio De-Embedding:

Receiver provides analog audio output for external audio system

  • HDCP 2.2 / HDCP 1.4 and DVI 1.0 compliant
  • 18Gbps video bandwidth
  • HDMI loop output on the transmitter
  • With bi-directional IR, RS-232 and CEC pass-through
  • Compact design for easy and flexible installation
  • Durable metal housing

Video

Additional information

Weight 2.00 lbs
