ICRealtime ECS1528FP Cloud Managed 24-Port Gigabit PoE+ Switcher 410W / 4x10Gb SFP+ Uplink / Layer 2+

Description

Download Manual

The ECS1528FP is a cloud managed Layer 2+ gigabit switch designed to deliver centralized network control and power over Ethernet for large installations. It provides 24 10/100/1000 Mbps ports with PoE+ support and a 410W total PoE budget that supports dense device deployments. Built for reliability, the unit supports cloud or on-premises management to match administrative preferences and security policies.

Key features include full Layer 2+ switching, a 128 Gbps switching capacity and four dual-speed 10Gb SFP+ uplink ports for high-bandwidth aggregation. All 24 copper ports support 802.3at/af to power cameras, access points and phones while preserving uplink bandwidth via SFP+ slots. The ECS1528FP also supports VLANs, L3 static routing and advanced QoS to maintain predictable traffic performance.

Under the hood the switch includes 512MB SDRAM and 128MB flash memory to store configurations and run advanced software features. The device maintains a 16K MAC address table, 10K jumbo frame support and multicast capabilities including IGMP and MLD snooping. Security and control features include ACLs, 802.1X RADIUS authentication and DHCP snooping to protect network integrity.

Management options cover EnGenius Cloud, SkyKey, ezMaster and a local web GUI for flexible deployment models. SNMP v1/v2c/v3 and RMON support provide monitoring and integration with existing network management systems. The unit also supports CLI access via SSH and Telnet for scripted provisioning and firmware management via TFTP.

Connectivity is provided via 24 gigabit RJ45 ports and 4 10Gb SFP+ fiber uplinks to connect distribution and core layers. LEDs indicate power, fault, PoE max, LAN mode and per-port link/activity/speed to simplify troubleshooting. Environmental tolerances support operating temperatures from 0°C to 50°C and non-condensing humidity up to 95%.

Installation is straightforward for rack or cabinet environments and the switch is optimized for enterprise surveillance, wireless and VoIP deployments that require centralized PoE power and high-capacity uplinks. Firmware features and management flexibility make the ECS1528FP a practical choice for administrators seeking granular control and scalable aggregation. The combination of PoE budget, SFP+ uplinks and Layer 2+ features delivers strong value for converged network environments.
