Kramer DIP-31 4K60 4x2x0 HDMI/Computer Graphics Automatic Video Switcher

Description

Download Manual

The DIP−31 is a 4K@60Hz (4:2:0) automatic switcher for HDMI, VGA, Ethernet,
data and unbalanced audio signals. It supports various modes of input selection and
transmit the signal via HDMI cable to a compatible receiver (for example the
VS−62H or a display/projector). The device is a Step−in commander when
connected to a matrix switcher that supports Step−in over HDMI such as the
VS−62H. It also features RS−232 commands to support monitor/projector on/
off.

Features:

• Max. Resolution — 4K@60Hz (4:2:0) and WUXGA.
• Max. Data Rate — 10.2Gbps (3.4Gbps per graphic channel).
• HDTV Compatible.
• HDCP Compliant — With sources that support HDCP repeater mode.
• HDMI Support — Deep Color, x.v.Color™ and 3D.
• Automatic Live Input Detection — Based on video clock presence.
• Automatic Input Selection — Based on priority selection or last connected
  input.
• Manual Input Selection.
• Step–in Support.
• Automatic Analog Audio Detection & Embedding.
• Convenient Control — Via Kramer Protocol 3000 and embedded Web pages over
  a LAN.
• RS–232 Command Support.
• I–EDIDPro™ Kramer Intelligent EDID Processing™ —
  Intelligent EDID handling & processing algorithm ensures Plug and Play operation
  for HDMI systems.
