Description
Aurora’s DTX-6464D is a Dante enabled, all digital, audio DSP Aggregator. This fully networked family of professional audio products is ideal complement to Aurora’s IPX and VPX Video over IP solutions for House of Worship, Bars and Restaurants, Conferencing, and Education markets. The DTX ecosystem of products are purpose built to deliver pristine audio throughout the network while significantly reducing traditional device count and cabling costs.
DTX products use the industry-leading ADI 450Mhz SHARC 21489 chip and provides outstanding 24bit/48kHz audio quality.
The DTX-6464D is a high-density aggregator which features 64×64 Dante I/O. It is perfect for large centralized applications with multiple rooms or zones. In large, distributed systems that include analog I/O, significant benefits can be gained by using and aggregator vs a centralized DSP. This topology allows the DSP processing load to be distributed to smaller DSPs saving cost and adding survivability. The audio quality of the analog I/O also benefits by having the DSP connections close to the endpoints eliminating long analog runs, therefore reducing hum, buzz and ground loops.
Features:
- ADI SHARC 21489 processor
- 2 Dante audio interfaces on RJ-45 connectors
- 8 GPI/O multi-function ports on Terminal Block connectors
- Dante audio channels up to 64×64
- Definable GUI for managing and confgurating multiple units
- All Inputs and Outputs support a full suite of audio shaping tools
- 8 preset slots to store all configuration data for easy recall
- Built-in USB sound card for recording and playing digital audio
- DSP Confgurator software tool for managing all audio operations
