Description
The HBT-12 is an HDBaseT receiver designed to interface between transmitting and receiving devices. The receiver accepts up to 4K image quality video.
With the 56V power connected to one end of the HBT-12 HDBaseT receiver, the HBT-12 will thus be able to power the transmitting device by PoE plus technology (PoE++). Please only use Cat 7 Ethernet cables to connect PoE++ powered devices.
HDBaseT connection between the transmitter and the receiver can be established using a single Ethernet cable. In other words, HDMI video, DVIP control commands and power (PoE++) can be transmitted between the transmitter and the receiver over just one cable.
Features:
- Receives up to 4Kx2K video from the transmitter.
- Extends video transmission to 120m (maximum).
- Transmits video, audio, DVIP control, RS-422/232 control and PoE+ over a single Cat 7 cable.
- 56V PoE+ Power supply.
- DVIP Control Protocol
- RS-422/232 Control Protocol
