Description
The BG-MVS4X4-4KL 4K60 4:4:4 HDMI matrix is a versatile high-speed matrix switcher and video wall processor with multiple applications. This system can be configured for two different output modes, serving as a 4×4 seamless matrix switcher or as a 2×2, 4×1, or 1×4 video wall solution, among other possibilities.
Additionally, it is equipped with a web browser interface module for convenient control and configuration when used either as a standalone device or in conjunction with a third-party control system. Control options include front-panel push buttons, an IR remote control, RS-232 interface, and TCP/IP connectivity.
Features
- Compliant – HDMI 2.0b, HDCP 2.2 and HDCP 1.4
- 2 Operational Modes – 4×4 Matrix (seamless switch), Video wall (2×2, 4×1 or 1×4 etc configuration)
- Audio Formats – Support LPCM, DD, DD+, DTS, Dolby TrueHD, DTS HD-master pass-through
- Advanced EDID management – Seamless communication between sources and displays
- Web Interface Module – For control and configuration of Matrix
- Control Options – Control via front panel, IR, RS-232, and TCP/IP
- Seamless video switching
- Video inputs support all industry standard video resolutions including VGA-WUXGA (up to 1920 x 1200 @ 60Hz) and 480i-4K (3840 x 2160 @ 60Hz 4:4:4, 4096 x 2160 @ 60Hz 4:4:4)
- HDMI outputs support upscale or downscale to any resolution, up to 4096 x 2160 @ 60Hz 4:4:4
- 3rd Party drivers are available for all major home control brands
