Description
Download Manual VZX-8 is the core of a powerful zone audio platform with advanced DSP functionality designed to meet the diverse needs of commercial fixed installations. It reliably handles music, paging, messaging and control with maximum ease and flexibility. VZX-8 is ideal for a variety of applications, such as:
- Bars / Restaurants
- Hospitality Venues
- Retail Outlets
- Fitness Centers
- Houses of Worship
- Education
- Corporate Spaces
- Warehouse
VZX-8 allows system designers to get professional results while providing venue operators with easy, intuitive controls for volume, source, and zone management. It features extensive I/O, flexible control and advanced DSP functionality including a virtual mixer with AMM. The intuitive VZX Web App enables fast system configuration, setup, and control. Get online instantly using Included URLs and ZeroConf technology; no downloads or apps needed! Access on any device with a browser – a familiar and intuitive workflow eliminates the need for lengthy trainings and certifications.
Features
- 20 processed input sources including 8 HighQuality Mic/Line inputs
- Full Matrix DSP: input EQ, compression, AGC, ANC,
- Noise Gate, Dynacord FX, room EQ, speaker EQs with FIR and more
- Virtual Mixer with Automixer (AMM) and FX available for live mixing on any zone
- 32 GB MicroSD card included for storing music, messages and configuration files
- Compatible with SONICUE speaker databases for
- Electro-Voice Loudspeakers and more: maximize the performance of your system, instantly
- Flexible Control: 8 X GPIO, ethernet control with TCP/IP, JSON RPC;
- 2 x RJ45 Accessory ports work reliably with cable lengths up to 1640 feet (500M) per port, allowing 16 devices total;
- 2 x RJ45 Line Outputs to V-Series amplifiers for fast connections;
- Add VCS-8 Call Stations for zone paging and system control;
- Add VWP Wall Panel Controllers for level, zone, source control with Unicode for 150+ languages.
