Aten US3384I 8 x 4 USB 3.2 Gen 1 Industrial Sharing Switch

Description

Elevate Your BYOM/BYOD Meeting Experience

Driven by the shift to hybrid and remote work, the US3384i is designed to enhance your meeting experience with ease. Meeting room setups are straightforward, thanks to its plug-and-play design that supports connections to up to 8 PCs/laptops and sharing of up to 4 USB 3.2 Gen 1 devices in no time. With blazing-fast data transmission, cross-platform compatibility (Windows, macOS, Linux), and flexible port-switching, the USB sharing switch streamlines workflows, enhances collaboration, and reduces IT overhead.

Plug in – Collaborate – Share in Seconds

Join the meeting anytime to start discussions, share data, or switch between devices – all in just seconds.

Seamless Integration into Control Systems

The US3384i integrates with reputable control systems (including ATEN’s VK1100A, VK211) via serial connectivity, enabling IP control. This centralizes AV/IT management, simplifying maintenance and streamlining meeting room operations.

Auto-Switch for Efficient Control

The US3384i automatically shifts PC focus to the most recently connected host device. The corresponding port LED indicates which active port currently has control over the resources.

Up to 5 Gbps Data Transfer Rate with USB 3.2 Gen 1

Maintain efficient meeting flows with superior 5 Gbps data transfer speeds of USB 3.2 Gen 1 ports. Backward compatible with USB 2.0 / 1.1 devices.

Maximize Project Versatility with Dual Power Support

Flexible deployment with dual power options: a DC12V adapter for meeting room applications, or a DC9-24V terminal block for industrial environments.

Industrial-Grade Design for Durability and Stability

The robust metal casing shields against unwanted objects, providing high durability and stability for industrial and high-traffic environments.

Features

Built to take your BYOM/BYOD experience to the next level, the US3384i allows sharing of up to 4 USB 3.2 devices, such as keyboards, mice, cameras, speakerphones, and sound bars, among 8 PCs to declutter workspaces while permitting smooth USB content sharing across multiple meeting participants.

Conferences are kept disruption-free thanks to its blazing fast bandwidth speed of 5 Gbps and the backward compatibility with USB 2.0/1.1 devices, ensuring swift data transmission. In addition, the US3384i boasts versatile port selection methods, including the pushbutton on the front, the RS-232/RS-485 serial commands, and the external remote port selector*, which add more flexibility to its operation. The US3384i supports Power on Detection function, which automatically switches the PC focus to the last plugged-in/poweredon host device. What is more, the priority port preference is configurable, allowing the focus to switch to a secondary USB host when the primary one is lost. The front-panel port status LEDs illuminate to indicate which one of the PCs connected to the US3384i is having the focus at a glance.

In terms of installation, the US3384i comes with plug-and-play support on Windows and macOS operating systems, meaning no drivers are needed. It is also hot-pluggable, so users can connect/disconnect the host devices dynamically to the US3384i without powering off the switch. The case is constructed with premium metal for enhanced durability and supports wall-mounting to meet more installation requirements.

*The remote port selector is sold separately. Please contact your ATEN dealer for product information.

• Allows sharing of up to 4 USB 3.2 devices among 8 PCs
• Bandwidth speed of 5 Gbps and backward compatibility with USB 2.0/1.1 for swift data transmission
• Versatile port selection methods – front panel pushbutton, RS-232/RS-485 serial commands, and external remote port selector¹
• Power-on Detection:
  – Automatically switches the PC focus to the last plugged-in/powered-on host device
  – Configurable priority port preference allows switching to a secondary USB host if the primary one is lost
• Front panel port status LEDs indicate which PC currently has focus
• Supports USB BC 1.2 to ensure sufficient power for downstream USB devices
• Overvoltage protection circuit – extends device lifespan and minimizes risks of electrical hazards or voltage spikes
• Supports DC 9–24V power input through terminal block²
• Plug-and-play on Windows and macOS – no drivers required
• Hot-pluggable – dynamically connect/disconnect host devices without powering off the switch
• Wall-mountable case constructed with premium metal for enhanced durability

Notes:

1. The remote port selector is sold separately; please contact your ATEN dealer for product information.
2. Supports either of the following power supplies:
   (1) DC terminal block
   (2) DC power jack (The power adapter (0AD8-8012-50M2) is sold separately; contact your ATEN dealer)
