Aten SN1132CO 32-Port Serial Console Server with Dual Power / SFP

Description

ATEN SN11xxCO Series (SN1116CO / SN1132CO / SN1148CO) serial console server provides IT and network administrators secure, out-of-band access to serial devices located at data centers or remote sites (such as network switches allowing console operation using RS-232 and USB console1). With dual power/SFP2 in the SN11xxCO models, all of them integrate cutting edge technologies to provide convenient installation, secure serial device access, easy management and comprehensive control for data centers.SN11xxCO series also supports USB 4G dongle3, for additional out-of-band network access.

All series of serial console server features Cisco pin-outs and auto-sensing DTE / DCE function, providing a direct connection to Cisco network switches (and other compatible devices) without rollover cables for more time-saving IT infrastructure deployment. In addition, it support online detection of connected serial devices (including terminal blocks) for device status monitoring. An e-mail notification will be sent to the administrator when connected devices are offline. With dual Ethernet ports and power supplies (AC), the SN11xxCO supports power redundancy as well as failover, or dual IP addresses access, ensuring 24 / 7 availability of access to serial devices. A DC power option is also available for each of the SN11xxCO/SN01xxCO model for more flexible implementation4.

The SN11xxCO Series supports environmental monitoring through its sensor ports, remaining vigilant around the clock to detect any abnormal conditions. It offers audited and controlled door access using a cabinet lock through its relay port, enhancing security measures. All of the serial console servers can be utilized through ATEN’s CC2000 software to provide centralized serial device access and integrated power management.

Available in 16-, 32- and 48-port models, the SN11xxCO serial console servers offer both in-band and out-of-band (OOB) remote serial console and USB console access to servers and network devices via a direct Telnet / SSH client, Java viewer and WebClient. The OOB management enables IT administrators to manage network devices (e.g. router, switch, UPS) in server rooms using management networks that are separated from the main / production networks. Where access difficulty occurs in the production network, the administrators can still access them via the console server. The serial console servers offer out-of-band access methods such as direct console connection from a local computer, USB console connection from a laptop, or hybrid network connection via the dual SFP (one connected to the production network and the other connected to the management network).

Implemented with various security technologies such as TLS 1.2 data encryption, RSA 2048-bit certificates,configurable user permissions for port access and control, local / remote / third-party authentication and authorization, IP / MAC address filter, and FIPS 140-2 certified cryptography, the SN11xxCO serial console servers assure administrators the security for easy and high-level access. For instance, access rights and privileges can be applied to 16 / 32 / 48 serial ports individually. Data encryption is provided to ensure that information and control are always protected. Logging and alerting of system events help to quickly resolve issues and mitigate risks.While secured by the above examples, the consolidated password authentication simplifies management.

The serial console servers are used to connect serial devices to an Ethernet network to allow access and control of demanding applications that manage industrial control, data acquisition, environment monitoring, remote facility operations and equipment management. Multiple operational modes are available to administrators including Console Management, Console Management Direct, Real COM Port, TCP Server / Client, UDP Server / Client, and Virtual Modem.

With their comprehensive features, the SN11xxCO Series help to maximize IT productivity, increase scalability, as well as reduce installation and operational costs with easy and secure remote management of serial devices. The serial console servers save you time and money by allowing administrators to manage their data centers from practically anywhere – minimizing travel and MTTR (Mean Time to Repair) costs, and ensuring the highest availability for data center services.

Note: 1. Compatible models: Cisco Catalyst 2960-C series 2. Fiber (2A-136G, 2A-137G) or copper (2A-143G) modules are sold separately. Please order with SN devices together. 3. This device only supports the ZTE MF79U USB 4G dongle. 4. DC power models include SN1116COD, SN1132COD, SN1148COD, SN0108COD, SN1116COD, SN0132COD, and SN0148COD.

Features

System Accessibility and Availability

Secure in-band and out-of-band remote serial console and USB console access
Browser access with an intuitive GUI
Terminal-based access via menu-driven UI or command-line interface
Modem dial-in / dial-back / dial-out access
Front USB ports for storage, USB console¹, and UC232B / UC232BF connection
Laptop USB Console (LUC) port for local console access via laptop
Dual Ethernet ports for failover control or dual IP address access
Dual power supply
USB 4G dongle support for cellular out-of-band redundancy²

Serial Console Management

Sensor ports for environmental monitoring³
Relay port for cabinet door access control
Auto-sensing DTE / DCE supports direct connection to Cisco network switches (and other compatible devices) without rollover cables
Online / Offline detection of connected serial devices (including terminal blocks) with automatic event notifications (e.g. power failure)
Response Check monitors system status of connected serial devices and sends notifications on failure (e.g. system crash)
Serial device access via Telnet / SSH and third-party clients such as PuTTY
Easy port access via ActiveX, Java serial viewer, or WebClient
Comprehensive viewer functions including copy/paste, logging, data import, macros, broadcasting, and message board
Sun Solaris ready – Sun “break-safe”
Alert Strings generate SNMP Trap alerts and/or email notifications when predefined strings are detected
Command filter to restrict users to predefined commands
Up to 16 simultaneous user connections per port
Simultaneous access modes: Exclusive / Occupy / Share

Security

TLS 1.2 encrypted browser login with RSA 2048-bit certificates
Configurable user permissions for port access and control
Local and remote authentication support
Third-party authentication via RADIUS, TACACS+, LDAP / AD, and Kerberos
IP and MAC address filtering
FIPS 140-2 Level 1 security compliance using an embedded FIPS 140-2 certified OpenSSL cryptographic module (Certificate 1747, 2398, 2473)
Configurable security levels: High, Medium-high, Medium, or Custom
IEEE 802.1X compliant
SSH password-less login for enhanced security and simplified access

System Management

System configuration via web browser, Telnet / SSH client, and local console
System log and event logging
Event destinations include Log server, Syslog server, and USB drive³
SNMP agent v1 / v2c / v3
Event notifications via SMTP email and SNMP Trap (v1 / v2c / v3)
Backup and restore system configuration with firmware upgrade support
Multi-browser support: Internet Explorer, Chrome, Firefox
NTP support for time synchronization
IPv4 and IPv6 support
LLDP support
CLI (Command-Line Interface) support
Integration with CC2000 centralized management software
Integration with CCVSR software for user session recording

Serial Device Management

Serial operation modes: Console Management, Console Management Direct, Real COM Port, TCP Server / Client, UDP Server / Client, and Virtual Modem
Real COM driver support for Windows 2000 or later and Windows Server 2003 / 2008
Real TTY driver support for Linux
Fixed TTY driver support for UNIX⁴
Supports baud rates: 300, 600, 1200, 1800, 2400, 4800, 9600, 19200, 28800, 38400, 57600, 115200, and 230400 bps

Language

Multi-language web-based GUI available in English, German, Japanese, Korean, Russian, Simplified Chinese, and Traditional Chinese

Note:
1. Compatible models: Cisco Catalyst 2960-C series.
2. Supports ZTE MF79U only.
3. Achieved using ATEN sensors.
4. Fixed TTY driver supports OpenServer (SCO Unix), UnixWare 7, SVR5, UnixWare 2.1, SVR 4.2, QNX 4.25, QNX 6, FreeBSD, Solaris 10, AIX 5.x, and HP-UX 11i.

Specifications

Connectors
Serial	32 x RJ-45 Female
LAN Ports	2 x SFP Slot
Power	2 x IEC 60320/C14
Local Console	1 x RJ-45 Female
PON	1 x RJ-45 Female (Reserved)
Laptop USB Console (LUC) Port	1 x Mini USB
USB Port	4 x USB Type-A Female
Environment Sensor Ports	2 x RJ-11 Female 1 x 4-Pin Terminal Block
Relay	1 x 2-Pin Terminal Block Normally open, isolated relays Contact Rating: Max 24 VDC, 2A
Switches
Power	2 x Rocker Switch
Reset	1 x Recessed Pushbutton
Power
Maximum Input Power Rating	100–240VAC, 50/60Hz, 1.0A
Power Consumption	AC110V: 11.2W / 105 BTU/h AC220V: 11.3W / 105 BTU/h
LEDs
Serial	32 (Green)
10/100/1000 Mbps	2 (Red / Orange / Green)
Power	2 (Blue)
Mode of Operation
Supported Modes	Console Management Console Management Direct Real COM Port TCP Server / Client UDP Server / Client
Environmental
Operating Temperature	0 – 55°C
Storage Temperature	-20 – 60°C
Humidity	0 – 80% RH (Non-condensing)
Physical Properties
Housing	Metal
Weight	4.60 kg (10.13 lb)
Dimensions (L × W × H)	43.84 × 32.84 × 4.40 cm

Note:
The measurement in Watts indicates the typical power consumption of the device with no external loading.
The measurement in BTU/h indicates the power consumption of the device when it is fully loaded.

SN1132COD with dual DC power is available upon request.
Optional fiber modules (2A-136G, 2A-137G) or copper module (2A-143G) are available.
Optional sensors (EA1140, EA1240, EA1340, EA1440, EA1441, EA1442, EA1540) are available.
For some rack mount products, physical dimensions are expressed using an L × W × H format.
