| K-IIT XL Picture-in-Picture Image Insertion Technology | PIP / PAP / Split screen, window positioning |
| K-Storm Scaling Technology | High performance scaling, low motion artifacts |
| Ultra-Fast Fade-Thru-Black (FTB) Switching | Fade to black transitions, constant sync |
| Advanced EDID Management | Per-input EDID, master output analysis |
| HDTV Compatible | Yes |
| HDCP Compliant | HDCP pass-through on HDMI |
| Video Inputs | 2 HDMI, 1 DisplayPort, 2 VGA, 1 Component (Y Pb Pr), 2 Composite |
| Scaled Outputs | 1 HDMI, 1 VGA, 1 DGKat RJ-45 |
| Multiple Output Resolutions | 640x480@60-75, up to 1920x1200@60, 2048x1080@50/60, 480i/p to 1080p |
| HDMI Deep Color Support | Supported |
| Luma Keying | Via PIP window |
| Vertical Keystoning | Supported |
| Built-in ProcAmp | Color, sharpness, contrast, brightness, gamma per input |
| 3D Comb Filtering | Composite color separation |
| Built-in Time Base Corrector | Stabilizes unstable video sources |
| Noise Reduction Filters | Temporal, block, mosquito, combing |
| Picture Zooming | Up to 1600% main and PIP |
| De-interlacing | 3:2 and 2:2 pull-down, 24sf handling |
| Aspect Ratio Selections | Follow input, follow output, best fit, letterbox, overscan |
| Dual Window Display | Preset PIP, PAP, split screen, custom layouts |
| Audio Inputs | 2 HDMI, 2 VGA, 1 DP, 2 CV, 1 S/PDIF, 1 mic |
| Audio Outputs | 1 S/PDIF, 1 unbalanced stereo terminal block, 2x10W amp speaker outputs |
| Audio Controls | Input/output level adjustment, audio delay, mic mix and talk-over |
| Power Saving Modes | Selectable |
| Non-Volatile Memory | Saves final settings |
| Firmware Upgrades | Ethernet, RS-232 |
| Control Methods | Front panel, OSD, IR remote, RS-232, Ethernet, contact closure |
| Power Consumption | 100-240V AC, 56VA max |
| Dimensions | 19" x 9.3" x 1U |
| Weight | 2.5kg 5.5lbs approx |
| Accessories | Power cord, rack ears, IR remote, control app |
| Compliance | HDMI, HDCP, DisplayPort 1.1a |
