EVF-1152D/43-PIB Speaker 15in 40x30 Weatherized

Specifications

15'' Low Frequency transducer	FEA optimized woofer
3" titanium compression driver	1.4'' throat diameter
Rotatable CD horn	12" x 12"
Frequency response	49 Hz - 21 kHz +/-2 dB
Crossover	4th order 24 dB/oct HF protection
Acoustic crossover frequency	1300 Hz
Protection circuit	Dynamic thermal protection
Operation mode	Bi-amp or passive switchable
Enclosure shape	Trapezoidal
Enclosure material	13-ply birch plywood
Flying hardware	Optional
Color / Finish	Black textured paint
Input connector	Phoenix panel up to 10 AWG
Operation mode switch	External accessible
Grille	Powder-coated steel with acoustic foam
Ingress protection	ANSI/IEC 60529 IP55
Maximum sustained humidity	<80%
Salt content of normal air	<20%
Grille / Fasteners	Stainless steel
Frequency Range (-10 dB)	40 Hz – 21
Suspension	22 M10 threaded suspension points, EBK-M10-EVI kit included
Weatherized	No
Minimum Impedance	6
Nominal Impedance (Passive)	8
HF Transducer	3" DH7N
Speaker Type	Full-Range, Two-Way
Frequency Response (-3 dB)¹	70 Hz – 18
LF Nominal Impedance	8
Max. SPL/1m (calc)²	134
Coverage (Nominal -6 dB) H	40
Coverage (Nominal -6 dB) V	30
LF Transducer	15" DVX3151A
System Power Handling (Continuous/Program/Peak)	600, 1200, 2400
Crossover Frequency	1300
Enclosure Material	13-ply weather-resistant birch
Grille	Std:16ga Galvanneal Powdercoat; PI/FG:18ga Stainless Powdercoat hydrophobic cloth
Sensitivity 1 W/1 m	100
Height	768.6
Width	469.8
Recommended High-Pass Frequency	45
Depth	466.6
Weight Net	34.4
Shipping Weight	39.1
Net Weight	75.7 lb (34.4 kg)
Dimensions (H x W x D)	30.26" x 18.5" x 18.37" (768.6 x 469.8 x 466.6)
Input Connections	Euroblock; PI/FG versions include dual-gland-nut cover
Available Coverage Patterns (Nominal -6 dB) HxV	40 x 30
Environmental Specs	Std: IEC 60529 IP44; PI/FG: IEC 60529 IP55
Internal Passive Crossover Frequency	1300
Passive Power Handling	2400
Color	Black
