| Max. Data Rate | 6.75Gbps, 2.25Gbps per channel |
| Secure Link | AES-128 |
| Connection Capacity | Up to 4 receivers, up to 3 transmitters per receiver |
| Transmission Range | 30m 100ft |
| Automatic Frequency Selection | Auto frequency selection |
| Auto EDID Adjustment | Auto EDID adjustment |
| IR Remote Control | IR passthrough, 3.5mm mini jack |
| OSD (On Screen Display) | On screen display |
| HDCP Compliant | HDCP 2.0 |
| Zero Latency | <1ms latency |
| Automatic Sleep Mode | 3 min no input |
| CEC Support | CEC |
| INPUT | 1 HDMI connector |
| OUTPUT | 1 IR 3.5mm mini jack, internal antenna |
| VIDEO RESOLUTION | Up to 1080p@60Hz, 8/10/12-bit, VESA 1920x1080@60Hz |
| FORMATS | RGB, YCbCr |
| MAXIMUM DATA RATE | 6.75Gbps, 2.25Gbps per channel |
| MAXIMUM PIXEL CLOCK | 148.5MHz |
| AUDIO FORMATS | PCM, Dolby Digital 2/0, Dolby Digital 2/0 Surround, Dolby Digital 5.1, Dolby Digital Surround EX, DTS 2-channel, DTS 5.1, DTS 96/24 |
| AUDIO RATE | Up to 6Mbps |
| RF COMMUNICATION FREQUENCY | 5.19 to 5.795GHz, Japan 5.15-5.25GHz, Israel 5.15-5.35GHz |
| TRANSMISSION POWER | <18dBm conducted (KW-14T), <12dBm per channel (KW-14R) |
| RECEIVING SENSITIVITY | -75dBm (KW-14T), -65dBm (KW-14R) |
| SYSTEM LATENCY | <1ms |
| STANDARDS | HDMI Deep Color, x.v.Color, 3D, CEC, HDCP 2.0, DVI 1.0 |
| RF COMMUNICATION FREQUENCY | 5.19 to 5.795GHz, Japan/Israel limited bands 5.15-5.25GHz |
| UNOBSTRUCTED TRANSMISSION RANGE | 30m 100ft |
| POWER CONSUMPTION | 5V DC, 1A |
| OPERATING TEMPERATURE | 0 to 40 C |
| STORAGE TEMPERATURE | -40 to 70 C |
| HUMIDITY | 10% to 90% RHL non-condensing |
| COOLING | Convection vented |
| ENCLOSURE TYPE | Plastic |
| DIMENSIONS | 8.0cm x 10.2cm x 3.6cm, 3.15" x 4.02" x 1.42" |
| WEIGHT | 0.1 kg 0.22lbs |
| SHIPPING WEIGHT | 0.45kg 1.0lbs |
| ENVIRONMENTAL REGULATORY COMPLIANCE | RoHS, WEEE |
| VIBRATION | ISTA 1A |
| COMPLIANCE STANDARDS | CE, c-UL, UL |
| EMMISSION STANDARDS | CE, C-tick, FCC Class B, ICES, VCCI, KC |
| INCLUDED ACCESSORIES | Power supply 5V, 2 HDMI cables 0.9m, 1 IR emitter cable |
