Kramer PN-6P 6.5”, 2-way, Passive Pendant Speaker

Description

Premium sound high performance, 2−way passive pendant speaker The Passive Pendant Speaker combines premium sound quality with a sleek, modern design, making it perfect for open−ceiling installations and spaces where aesthetics matter. Engineered as a coaxial speaker, it delivers clear, full−range sound suitable for background music and voice announcements. The speaker supports both 8Ω low impedance as well as several 70V/100V high impedance modes. This speaker offers exceptional sound and performance ideal for commercial environments. The speaker is available in both black & white colors

Features

Premium sound with high SPL
Low–impedance (8Ω) / high–impedance (70V/100V)
Power ratings: 30W continuous / 45W peak
Sensitivity (1W@1m, free field): 90dB SPL
Maximum SPL (@1m): Continuous: 105dB SPL / Peak: 107dB SPL
UL1480A certified for indoor installations
Industrial design: Available in black & white colors, removable logo
Eco–friendly mono–material packaging

Specifications

Audio
LF Driver	165 mm (6.5 in) high output driver with polypropylene cone and rubber surround
HF Driver	19 mm (0.75 in) liquid cooled soft–dome tweeter
Frequency Characteristics
Frequency Range (-10dB)	68Hz–20kHz
Frequency Response (±3dB)	87Hz–18kHz
Dispersion Angle	108° conical dispersion (1 kHz to 4 kHz)
Power Ratings
@ 8Ω Low Impedance	30W continuous / 45W peak
@ 100V High Impedance	30W / 15W / 7.5W
@ 70V High Impedance	30W / 15W / 7.5W / 3.8W
Sound Pressure Level (SPL)
Sensitivity (1W@1m, free field)	90dB SPL
Maximum SPL	Continuous: 105dB SPL / Peak: 107dB SPL
Mechanical
Installation Type	Pendant ceiling speaker
Mounting	4.5m (177”) long 2mm (0.08”) galvanized–steel suspension cable with spring–clip carabiner and gripple fastener; SWL rating 45 kg / 100 lbs
Connectors	4–pin pluggable Euroblock connector, 28–12AWG
Weight (Single Speaker)	3.2kg (7lbs)
Dimensions
Speaker Height (w/o Bracket)	270mm / 10.7”
Speaker Height (with Bracket)	333mm / 13.1”
Outer Diameter	224mm / 8.82”
Minimum Grill to Ceiling Distance	380mm / 15”
Product Dimensions (W x D x H)	25.50cm x 25.50cm x 31.50cm (10.04" x 10.04" x 12.40")
Product Weight	3.2kg (7.0lbs) approx.
Shipping Information
Single Unit	330mm x 330mm x 395mm (13" x 13" x 15.6")
Master Box (Single Unit)	438mm x 438mm x 351mm (17.3" x 17.3" x 13.9")
2 Units Master Box	668mm x 338mm x 413mm (26.3" x 13.3" x 16.3")
Shipping Weight (Single)	4.5Kg / 9.9lbs approx.
Shipping Weight (2 Units Master)	9.6Kg / 21.2lbs
Packaging	Eco–friendly mono–material recyclable carton packaging
Material
Grill	Black/White powder coated steel with cloth, removable logo
Baffle	V–0 Flame Retardant
Environmental
Operating Temperature	–5° to +50°C (23° to 122°F)
Storage Temperature	–10° to +55°C (14° to 131°F)
Humidity	30% to 85%, RHL non–condensing
Regulatory
Certification	UL1480A Certified
Environmental Compliance	RoHS, REACH, WEEE
In the Box
Speaker	1 speaker (single unit), 2 speakers packed in master box
Accessories	1 suspension cable kit
Connector	4–pin pluggable Euroblock connector (28–12AWG)
Documentation	Quick Start Guide
