ICRealtime NVR-MX08POE-1U-4KM1-2TB 8Ch NVR, 2TB HDD, Integrated 8 Port POE , 160 Mbps Bandwidth (80 Mbps when AI is enabled)

Description

IC Realtime’s NVR-MX08POE-1U-4KM1 packs features like 8MP/4K resolution support and output as well as H.265 encoding technology in a compact form factor, boasting excellent performance at an affordable price. This 8 channel NVR has a built in 8 port PoE for easy plug-and-play install with IC Realtime cameras. The NVR also supports a variety of Intelligence features by camera, such as Perimeter Protection and Intelligent Motion Detect for Human and Vehicle Recognition, as well as Face Detect. These features can be utilized by the NVR’s AI search.

Features

8 Channels | Up To 12MP | 160Mbps Bandwidth
1 HDD | 2TB
ICR OS 4.0 | 8-Port PoE | AI+ IVS Support
2 USB | 1 HDMI + 1 VGA
ONVIF Conformant | 1U | Desktop Mountable

Specifications

System
Main Processor	Industrial-grade embedded processor
Operating System	Embedded LINUX, ICR 4.0
Display
Display Interface	1 HDMI, 1 VGA
Display Resolution	HDMI: 3840 × 2160; 1920 × 1080; 1280 × 1024; 1280 × 720 VGA: 1920 × 1080; 1280 × 1024; 1280 × 720
OSD	Camera title, Time, Video loss, Camera lock, Motion detection, Recording
Display Split	Main Screen: 1/4/8/9 Sub Screen: 1/4/8/9
HDMI Decoding	AI Disabled: 1ch 12MP@30fps; 2ch 8MP@30fps; 3ch 5MP@30fps; 4ch 4MP@30fps; 8ch 1080p@30fps AI Enabled: 1ch 12MP@30fps; 1ch 8MP@30fps; 2ch 5MP@30fps; 3ch 4MP@30fps; 7ch 1080p@30fps
Display Out Max Decode	Simultaneous: HDMI: 3840 × 2160; 1920 × 1080; 1280 × 1024; 1280 × 720 VGA: 1920 × 1080; 1280 × 1024; 1280 × 720 Different Outputs: HDMI: 1920 × 1080; 1280 × 1024; 1280 × 720 VGA: 1920 × 1080; 1280 × 1024; 1280 × 720
Intelligence
IVS	People Counting, Heat Map, Tripwire & Intrusion (AI by Camera)
Advanced Intelligent Functions	Perimeter Protection (6 Channels; AI by Camera) Intelligent Motion Detect (4 Channels AI by NVR or 6 Channels AI by Camera) Face Detection (6 Channels; AI by Camera) Face Recognition (6 Channels; AI by Camera)
Video
Supported Camera Types	IP
IP Camera Input	8 Channels
Playback	1/4/8
Playback Function	1. Play / Pause / Stop / Slow / Quick / Backward / By frame 2. Full screen, Backup (video clip/file), Partial zoom in, Audio on/off
Backup Mode	USB Device, Network
Audio
Compression	G.711a; G.711u; PCM; G726
Two-way Talk	Supported
Recording
Record Compression	Smart H.265+; H.265; Smart H.264+; H.264
Record Resolution	12MP; 8MP; 6MP; 5MP; 4MP; 3MP; 1080p; 960p; 720p; D1; CIF; QCIF
Record Mode	General; Motion Detection; Intelligent; Alarm
Incoming Bandwidth	160 Mbps
Throughput	160 Mbps
Storage
Internal HDD	1 SATA III Port, up to 16TB (Starting at 2TB)
HDD Mode	Single
Network
Ethernet	1 × RJ-45 (10/100/1000 Mbps)
Protocol	HTTP; HTTPS; TCP/IP; IPv4/IPv6; UPnP; SNMP; RTSP; UDP; SMTP; NTP; DHCP; DNS; IP Filter; DDNS; FTP; Alarm Server; IP Search; P2P; Auto Register
Web Viewer	Chrome, IE 9+, Edge, Safari, Firefox
Management Software	IC Now; IC Now Pro
Smart Phone	Android; iOS; iPhone (IC View+)
PoE	8 Ports (10/100 Mbps, IEEE 802.3af/at), Bridge Mode
Interface
RS232	N/A
RS485	N/A
USB	2 (1 × Front USB2.0; 1 × Back USB2.0)
Audio I/O	1 Channel Input; 1 Channel Output (RCA); Two-way Talk Supported
Electrical
Power Supply	53 VDC, 1.81 A
Power Consumption	≤ 10W (Idling, without HDD)
Total PoE Budget	Total PoE Output: 72W Max per Port: 25.5W
Environmental
Storage Conditions	–4°F to +140°F (–20°C to +60°C)
Construction
Installation	Rack or Desktop Mount
Dimensions	1U, 10.24" × 9.15" × 1.98" (260 mm × 232.5 mm × 50.3 mm)
