WyreStorm NHD-600-E-RX NetworkHD 600-E Series 4K60 4:4:4 10GbE SDVoE Decoder

Description

The APO-VX20-UC v2 represents the next generation of all-in-one video bars and switchers, engineered to deliver a premium unified communication experience. It combines a high-performance array microphone, powerful stereo speakers, and an ultra-wide angle 4K camera into a single elegant device. With USB-C connectivity supporting 60W charging, HDMI input, dual HDMI outputs and seamless wireless casting through AirPlay, Miracast, and APO-DG2/APO-GD2-PRO with wireless casting and conferencing, the APO-VX20-UC v2 brings unparalleled versatility and simplicity to any professional meeting space.

Tailored for Corporate
The Apollo VX20 can be used in a myriad of conference applications from small huddle spaces up to larger corporate boardrooms. Very similar in use-case to the standard Apollo speakerphones, the VX20 carries over a lot of the same functionality such as USB-C and HDMI inputs for versatile connectivity options and the ability to wirelessly cast from personal devices via Airplay or Miracast.
LEARN MORE

4K CAMERA WITH ADVANCED AI FUNCTION
Featuring a newly upgraded large image sensor and powerful AI-driven tracking, including Auto Framing, Presenter Tracking, Speaker Tracking, and the newly added Individuals Gallery, delivering a more natural and immersive video conferencing experience.

PREMIUM AUDIO EXPERIENCE
Equipped with an 8-MEMS beamforming microphone array with Acoustic Echo Cancellation (AEC), Automatic Gain Control (AGC), and Automatic Noise Suppression (ANS), ensuring voices are captured clearly from up to 8 meters. Audio coverage can be expanded with up to 5 APO-SKY-MICs. Integrated stereo speakers with bass enhancement deliver clear, room-filling sound even in large meeting spaces.

WIRED & WIRELESS COLLABORATION
Supports both HDMI and USB-C with 60W charging for wired BYOD connectivity. Wireless casting is available via AirPlay, Miracast, and APO-DG2/APO-DG2-PRO, with wireless conferencing exclusively enabled through the APO-DG2/APO-DG2-PRO dongle for a truly cable-free meeting experience.

ROBUST OUTPUT CONNECTIVITY
Features dual 4K HDMI outputs with intelligent display management. Supports automatic source switching in dual-display mode, and multi-view content display on a single screen for enhanced meeting flexibility.

Additional Features

Lossless SDVoE video transmission over standard 10GbE networks
Supports resolutions up to 4096×2160 @ 60Hz
Full HDMI 2.0 and HDCP 2.2/2.3 compliance
True zero-frame latency for real-time AV applications
Point-to-point extender and scalable IP matrix operation
PoE+ (802.3at) power support for simplified installation
Flexible EDID management for source compatibility
Bidirectional IR passthrough over the network
Bidirectional RS-232 passthrough over the network
HDMI audio pass-through with multi-channel support
Analog audio de-embedding and routing
Compatible with managed 10GbE network switches
Auto-pairing support for fast point-to-point setup
Fail-safe firmware upgrade protection

Specifications

AUDIO & VIDEO
Inputs
TX	1x HDMI 19-pin Type A 1x 3.5mm TRS analog audio input 1x 10GbE 8-pin RJ45
RX	1x 10GbE 8-pin RJ45
Outputs
TX	1x 3.5mm TRS analog audio output (de-embedded from HDMI input)
RX	1x HDMI 19-pin Type A 1x 3.5mm TRS analog audio output (unbalanced stereo)
HDMI and analog outputs allow discrete audio routing from any available NHD-600 Encoder on the same network.
Video Encoding
SDVoE Pixel Pipeline 1080p@60Hz 8-bit – 3.4Gbps 4K@30Hz 4:4:4 8-bit – 6.4Gbps 4K@60Hz 4:4:4 8-bit – 8.7Gbps (light compression)
End-to-End Latency
Genlock mode: Uncompressed = 30µs, Compressed <120µs Fast switch mode: 1–2 frames (16.7–33.4ms @ 60fps)
Video Resolution (Max)
5120×2160p @60Hz (4:2:0) 5120×2160p @30Hz (4:4:4) 5120×1440p @30Hz (4:4:4) 4096×2160p @60Hz (8-bit 4:4:4 / RGB) 3840×2160p @60Hz (12-bit 4:2:2 Dolby Vision) 3840×2160p @60Hz (10-bit 4:2:2 HDR10/HLG) 1920×1080p @60Hz (12-bit) *5K supported only in genlock mode
Audio Formats
LPCM (2.0/5.1/7.1, 44.1/48/96/192kHz) Dolby TrueHD (up to 7.1, 192kHz) DTS-HD Master (up to 7.1, 192kHz) Dolby Digital AC-3 (DVD format) DTS (DVD format)
Communication & Control
HDMI	HDCP 2.2 / 2.3 \| CEC
RS-232	1x 3-pin Phoenix connector \| bidirectional \| API programmable
Ethernet	1x 1GbE RJ45
IR	1x IR TX 3.5mm TS mono (API programmable) 1x IR RX 3.5mm TRS stereo (API programmable)
Power
Supply	12V 2A DC PSU \| 802.3at PoE+ compliant
Consumption	Max 24W \| Average 10W
Environmental
Operating Temperature	0 to +45°C (32 to 113°F), 10%–90% non-condensing
Storage Temperature	-20 to +70°C (-4 to 158°F), 10%–90% non-condensing
Physical
Dimensions	145.2 × 150 × 25 mm (L × W × H)
Regulatory
CE \| FCC \| RoHS \| RCM \| EAC
