ICRealtime IPFX-B40V-IRW3 4MP IP Bullet Camera / Motorized 2.7-13.5mm Varifocal / PoE / IR 197ft / 120dB WDR

SKU: IPFX-B40V-IRW3
Brand: ICRealtime
$642.00
Brand ICRealtime
SKU IPFX-B40V-IRW3
Weight 3.00 lbs
Warranty 3 Years
Condition New
Status Available
Expert

Product Questions? Ask Our Experts!

Description

The IPFX-B40V-IRW3 is a 4MP network bullet camera engineered to capture high-resolution surveillance video for indoor and outdoor environments. It delivers 2688 × 1520 resolution at up to 30 fps, producing clear footage for identification and evidence. The camera combines a motorized 2.7 mm–13.5 mm varifocal lens and adjustable field of view to support a range of monitoring scenarios.

Key features include H.265 compression for reduced bandwidth and storage, 120 dB true WDR for balanced scenes, and 3D noise reduction for improved low-light clarity. Integrated IR illumination extends night monitoring to approximately 197 ft and the sensor supports color imaging down to 0.005 lux at F1.5. Intelligent analytics such as Perimeter Protection and Intelligent Motion Detect 2.0 reduce false alarms and enhance event relevance.

Technical performance is driven by a 1/3″ CMOS sensor, 128 MB RAM and 512 MB ROM, and triple-stream encoding to serve multiple simultaneous viewers. The camera supports multiple resolutions including 4M, 3M, 1080p and lower substreams for efficiency. Bit rate control supports CBR and VBR and Smart H.265+ reduces storage needs through scene-adaptive encoding.

Connectivity options include 10/100Base-T Ethernet with PoE (802.3af) and a 12 VDC input for flexible installation. The unit supports ONVIF S/G/T, IPv4/IPv6, RTSP/RTMP streaming, FTP/SFTP, and edge storage via microSD up to 256 GB or NAS. A built-in microphone and RCA audio ports expand situational awareness and recording capability.

This camera is well suited to perimeter monitoring, parking lot coverage, building entry points, and critical infrastructure sites where long-range IR and analytics are required. Intelligent Tripwire and Intrusion detection distinguish people from vehicles to reduce nuisance alerts and accelerate incident response. Object Search compatibility with IC Realtime NVRs aids fast forensic retrieval of recorded events.

Installation is simplified by motorized lens control, PoE power option, and an IP67-rated metal housing for weather resistance. The camera operates from -22° F to +140° F and tolerates wide voltage variation for outdoor deployments. IC Realtime backs the Flex series with a 10-year warranty and technical support to ensure long-term reliability.

Specifications

Camera
Image Sensor1/3" CMOS
Effective Pixels2688 (H) × 1520 (V) 4MP
RAM/Rom128 MB/ 512 MB
Scanning SystemProgressive
Minimum Illumination0.005 lux@F1.5 (Color 30 IRE)
Minimum Illumination0.0005 lux@F1.5 (B/W 30 IRE)
Minimum Illumination0 lux (Illuminator on)
Illumination DistanceDistance up to 197 ft (60 m)
Illumination On/Off ControlAuto / Manual
Illumination LEDs4
Camera Illumination TypeIR
Lens
Lens TypeMotorized vari-focal
Mount Typeφ14
Focal Length2.7mm~13.5mm
Max. ApertureF1.5
Angle of ViewHorizontal: 104°–29°
Angle of ViewVertical: 54°–16°
Close Focus Distance2.6 ft (0.8 m)
DORI - Detect209 ft -688 ft
DORI - Observe84 ft- 275 ft
DORI - Recognize42 ft- 137 ft
DORI - Identify21 ft- 68 ft
Intelligence
IVSTripwire; Intrusion
Advanced Intelligent FunctionsPerimeter Protection- Tripwire; Intrusion
Advanced Intelligent Functions NoteThese functions support the classification and detection of vehicle and human objects
Intelligent Motion Detect 2.0Advanced secondary filtering for human and motor vehicle , reducing false alarms caused by leaves, rain and lighting condition change. Supports Object Search with compatible NVRs.
Video
CompressionH.265; H.264; H.264H; H.264B; MJPEG
Streaming Capability3 Streams
Resolution4M (2688 × 1520); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/ 352× 240)
Frame RateMain Stream (2688 × 1520@1–25/30 fps)
Frame RateSub stream 1: 704 × 576 @ (1–25 fps)/704 × 480 @ (1–30 fps)
Frame RateThird Stream 1920 × 1080 @ (1–25/30 fps)
Bit Rate ControlCBR/VBR
Bit RateH.264: 3 Kbps–8192 Kbps
Bit RateH.265: 3 Kbps–8192 Kbps
Day/NightAuto(ICR) / Color / B/W
Backlight CompensationBLC, HLC, WDR
White BalanceAuto/natural/street lamp/outdoor/manual/regional custom
Gain ControlAuto / Manual
Noise Reduction3D DNR
WDR120dB
Audio
CompressionG.711a; G.711Mu; PCM; G.726; G.723
Network
EthernetRJ-45 (10/100Base-T)
ProtocolIPv4; IPv6; HTTP ;HTTPS;TCP; UDP;ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS;QoS;UPnP; NTP; Multicast;ICMP; IGMP;NFS; PPPoE; 802.1x ;SNMP
CompatibilityONVIF(Profile S/Profile G);CGI;P2P
Max. User Access20 (Total bandwidth: 64 M)
Edge StorageFTP; SFTP; Micro SD card (support max. 256 G); NAS
Web ViewerIE, Chrome, Firefox, Safari
Management SoftwareIC Now
Smart PhoneIOS, Android (IC View+)
Interface
Audio I/OBuilt-in Mic, 1 (RCA port) each output/ input
Alarm I/O1 channel in: wet contact, 5 mA 3 V–5 VDC; 1 channel out: wet contact, 300 mA 12 VDC
Memory SlotMicro SD card (support max. 256 GB)
Electrical
Power Supply12 VDC/PoE (802.3af)
Power ConsumptionBasic: 2.8 W (12 VDC); 3.6 W (PoE)
Power Consumption MaxMax. (WDR + IR intensity + Intelligence): 7.9 W (12 VDC); 9.2 W (PoE)
Environmental
Operating Conditions-22° F ~ +140° F (-30° C ~ +60° C) / Less than 95% RH
Storage Conditions-40° F ~ +140° F (-40° C ~ +60° C)
Ingress ProtectionIP67
Construction
CasingMetal
Dimensions9.61" × 3.11" × 3.00" (L × W × H) (244.1 mm × 79.0 mm × 75.9 mm)
Gross Weight2.4lb (1090 g)
Mounting Pan/Tilt/RotationHorizontal: 0°–360° Vertical: 0°–90° Rotation: 0°–360°
Additional Note1/2.9" 4 Megapixel progressive CMOS
Additional NoteH.265 & H.264 triple-stream encoding
Additional NoteOutputs max. 4MP (2688 × 1520) @25/30 fps
Additional NoteIntelligent Motion Detect 2.0, Perimeter Protection
Additional NoteBuilt-in Mic, AI SSA
Additional Note2.7~13.5mm Motorized varifocal lens
Additional NoteStarlight Support, Max IR distance: 197ft
Additional NoteIP67, PoE, Micro SD card slot, up to 256GB
Smart(H.265+)Scene adaptive encoding, dynamic GOP, dynamic ROI, multi-frame reference, intelligent noise reduction
Intelligent Video Analysis (IVS)Tripwire analytics, detection of predetermined line crossing
StarlightUltra-low light technology captures color details in low light
Perimeter ProtectionReduces false alarms up to 90% supports pedestrian/vehicle classification
iMD 2.0AI machine learning improves detection accuracy encodes detection metadata
Protection NoteIP67 rating integrated wiper for harsh conditions
Wide voltage±30% input voltage tolerance
