ECS1528FP PoE+ Switch 24-Port 410W 4x10Gb SFP+

Description

The ECS1528FP is a cloud managed Layer 2+ gigabit switch designed to deliver centralized network control and power over Ethernet for large installations. It provides 24 10/100/1000 Mbps ports with PoE+ support and a 410W total PoE budget that supports dense device deployments. Built for reliability, the unit supports cloud or on-premises management to match administrative preferences and security policies.

Key features include full Layer 2+ switching, a 128 Gbps switching capacity and four dual-speed 10Gb SFP+ uplink ports for high-bandwidth aggregation. All 24 copper ports support 802.3at/af to power cameras, access points and phones while preserving uplink bandwidth via SFP+ slots. The ECS1528FP also supports VLANs, L3 static routing and advanced QoS to maintain predictable traffic performance.

Under the hood the switch includes 512MB SDRAM and 128MB flash memory to store configurations and run advanced software features. The device maintains a 16K MAC address table, 10K jumbo frame support and multicast capabilities including IGMP and MLD snooping. Security and control features include ACLs, 802.1X RADIUS authentication and DHCP snooping to protect network integrity.

Management options cover EnGenius Cloud, SkyKey, ezMaster and a local web GUI for flexible deployment models. SNMP v1/v2c/v3 and RMON support provide monitoring and integration with existing network management systems. The unit also supports CLI access via SSH and Telnet for scripted provisioning and firmware management via TFTP.

Connectivity is provided via 24 gigabit RJ45 ports and 4 10Gb SFP+ fiber uplinks to connect distribution and core layers. LEDs indicate power, fault, PoE max, LAN mode and per-port link/activity/speed to simplify troubleshooting. Environmental tolerances support operating temperatures from 0°C to 50°C and non-condensing humidity up to 95%.

Installation is straightforward for rack or cabinet environments and the switch is optimized for enterprise surveillance, wireless and VoIP deployments that require centralized PoE power and high-capacity uplinks. Firmware features and management flexibility make the ECS1528FP a practical choice for administrators seeking granular control and scalable aggregation. The combination of PoE budget, SFP+ uplinks and Layer 2+ features delivers strong value for converged network environments.

Specifications

Product Highlights	Cloud Managed 24-Port Gigabit PoE+ Layer 2+ Switch 410W 4x10Gb SFP+
Cloud Managed 24-Port Gigabit 410W PoE+ Switch	Cloud Managed 24-Port Gigabit 410W PoE+
Layer 2+ Switch with 4 SFP+ Uplink Ports and Multiple Management Options for Large Businesses	Layer 2+ 4x SFP+ Multiple Management
24 10/100/1000 Base-T GbE Ports	24x 10/100/1000 Mbps
Full-Featured Layer 2+ Switching	Layer 2+
802.3 at/af PoE+ Ready on All Ports with 410W PoE budget	802.3at/af All Ports 410W
128 Gbps Switching capacity	128 Gbps
4 10-Gigabit Dual-Speed SFP+ (fiber) uplink ports	4x 10Gb SFP+
Port Standards - 802.3 10Base-T Ethernet	802.3 10Base-T
Port Standards - 802.3u 100Base-TX Ethernet	802.3u 100Base-TX
Port Standards - 802.3ab 1000Base-T Ethernet	802.3ab 1000Base-T
Port Standards - 802.3x Full-Duplex Flow Control	802.3x Full-Duplex Flow Control
Network Ports	24x 10/100/1000 Mbps, 4x SFP+
Switching Capacity	128Gbps
SDRAM	512MB
Flash Memory	128MB
PoE Capable Ports	1-24 (802.3at/af)
Total PoE Budget	410W
Power Source	100 ~ 240VAC 50-60Hz
Physical Interface - LED Indicators	Power LED, Fault LED, PoE Max LED, LAN Mode LED, PoE Mode LED
Physical Interface - Ports	Link/Activity/Speed per Ethernet port, Link/Activity/Speed per SFP slot
Software Features(L3 Feature) - Multiple IP Interface	Multiple IP Interface
Software Features(L3 Feature) - 20 IPv6 address	20 IPv6 address
Software Features(L3 Feature) - ARP Table	Max. 192 ARP entries
Software Features(L3 Feature) - Static ARP	Static 192 ARP entries
Software Features(L3 Feature) - IPv4 Static Route	Max. 63 entries
Software Features(L3 Feature) - IPv6 Static Route	Max. 21 entries
Software Features(L2 Feature) - Network Management	EnGenius Cloud, SkyKey, ezMaster, Local Web GUI
MAC Address Table	16K
Jumbo Frame	10K
Multicast Group	Max 256 groups
MLD Snooping	v1
QoS-Number of Priority Queues Supported	Queue 8
Trust Mode	CoS/802.1p, DSCP, CoS/802.1p-DSCP
Scheduling Mechanism	Strict, WRR, Strict + WRR
Bandwidth Control	Port-based bandwidth control Ingress/Egress
Port Security	Max. 256 Entries
Access Control List (ACL)	MAC Based ACL, IPv4/IPv6 Based ACL, ACL Binding, Time base ACL
Web Graphical User Interface(GUI)	HTTP IPv4/IPv6, HTTPS IPv4/IPv6
SSL Certificate	Certificate/Key Import
SNMP	SNMP v1/v2c/v3 Support
RMON	RMON 1,2,3,9
System Time	Time Setting, Daylight saving
Common L2 Features	802.1d Spanning Tree, Loopback Detection, Multicast Filtering, IGMP Multicast Forwarding, IGMP Snooping, MLD Multicast Forwarding, 802.1Q VLAN tagging, 802.3x flow control, 802.3ad Link Aggregation, IPv4 DHCP Relay, IPv4 DHCP Snooping, IPv4 DHCP Snooping Source MAC Address Check-up, ARP Inspection, ARP Packet Validation, Voice VLAN, Port-based VLAN, Protocol-Based VLAN, CoS Mapping, 802.1X Radius Authentication Protocol, IPv4 Settings, IPv6 Settings, IEEE 802.3az EEE, CLI, SSH Server, Telnet Server, TFTP Client, Config Upgrade/Backup, SNTP, SYSLOG
Environmental & Physical - Temperature Range	Operating 32°F to 122°F (0°C to 50°C)
Humidity (Non-Condensing)	Operating 5% - 95%
Package Contents	1x ECS Managed Gigabit Switch, 1x Quick Installation Guide, 1x Power Cord
