Aurora Multimedia DXE-CAT-S1-4K HDMI HDBaseT CAT Extender (Transmitter/Receiver) 70m/230ft Kit

Description

The DXE-CAT-S1-4K is part of the growing Digital Xtreme Series. This product is different than the typical CAT extender found on the market today as it not only breaks the price barrier but the feature and usability aspects as well. All connectors are on one side to make wiring cleaner and rack mounting easier. Having the ability to power the device with the choice of transmit or receive reduces the installation time and keeps things neat. An industry first is Aurora’s exclusive FlexPowerTM circuit (Patents Pending), which allows both the transmitter and receiver to be powered from either side with the one wall supply. Being able to go the distance is important too, and HDBaseT technology helps achieve that. With a single CAT cable, the DXE-CAT can go up to 131ft 4K 30Hz and 230ft 1080p 60Hz 36bit color depth depending on model and cable. In addition, the RS-232 and IR can be sent over the same cable bi-directionally.

Features

Transmit HDMI up to 1080p 60Hz 36bit 230ft*
Supports 4K 30Hz UHD & HDMI 3D 131ft*
HDCP Compliant
All connectors on one side for easier installation
Bi-directional RS-232 & IR
Power both units from TX or RX side with wall power supply (HDBaseT POE)
Status LED for all connections on front
Various mounting options

Specifications

Video
HDMI Compliance	HDMI 3D
HDCP Compliant	Yes
Distance	230ft [70m]
Max Resolution	4K 30Hz (340MHz)
Color Depth	48bit
Connectors
TX Connectors	(1) HDMI in, (1) HDBaseT, (1) RS-232 3.5mm TRS, (1) IR 3.5mm TRS
RX Connectors	(1) HDMI in, (1) HDBaseT, (1) RS-232 3.5mm TRS, (1) IR 3.5mm TRS
Mechanical
Dimensions	4.7" x 3.03" x 1.1" [120 x 77 x 28mm]
Weight	0.87lbs [395g]
Mounting	Wall mounting tabs (included) Rack mount bracket (included)
Power
Power Supply	24V 0.65A DC 5Watts
Environmental
Operation Temperature	32~104°F [0~40°C]
Storage Temperature	-4~140°F [-20~60°C]
Relative Humidity	20~90% RH [no condensation]
