| Specifications | |
|---|---|
| Mechanical Specifications | |
| Image Sensor | 1/2.7" Progressive Scan CMOS |
| Min. Illumination | 0.002 Lux @ (F1.2, AGC ON), 0 Lux with IR |
| Shutter Speed | 1/5 s – 1/20,000 s |
| Lens Type | 3.6 mm |
| Lens Mount | M12 |
| Day and Night | IR Cut Filter with Auto Switch |
| Dynamic Range | Digital WDR |
| Digital Noise Reduction | 3D DNR |
| Compression | |
| Video Compression | H.265 / H.264 |
| Image Resolution | 5MP (2592 × 1520) |
| Video Bit Rate | 256 Kbps – 8 Mbps |
| Image | |
| Frame Rate – Main Stream |
5MP (2560 × 1960): 1–15 FPS 4MP (2592 × 1520): 1–20 FPS 3MP (2048 × 1520): 1–30 FPS 1080P (1920 × 1080): 1–30 FPS 720P (1920 × 720): 1–30 FPS 7960H (1280 × 960): 1–30 FPS |
| Frame Rate – Substream |
VGA (640 × 480): 1–15 FPS QVGA (320 × 240): 1–15 FPS |
| Image Settings |
Rotate Mode, Saturation, Brightness, Contrast, Sharpness, Adjustable via Browser |
| Day and Night Switch | Day / Night / Auto / Schedule |
| Interface | |
| System Compatibility | ONVIF Ver. 2.6 |
| Network Interface | 1 × RJ45 10M / 100M Ethernet |
| IR Distance | Up to 90 ft |
| PoE | Built-in PoE |
| Security |
Flash-Prevention, Dual Stream, Heartbeat, Mirror, Password Protection, Privacy Mask, IP Address Filtering |
| Electrical | |
| Power Supply | 12 VDC / PoE |
| Power Consumption | ≤ 7 W |
| Operating Temperature | -40°F ~ 140°F, ≤ 95% RH (Non-condensing) |
| Physical | |
| Dimensions | 5.9” × 2.75” |
| Net Weight | 0.72 lb |
| Weather Rating | IP67 |
