Blackmagic Design BMD-CONVNVIPJ/STD/12G 2110 IP UHD 4K UpDownCross 12G Converter

Description

Convert any incoming video source to the video standard you are working with using the 2110 IP UHD 4K UpDownCross 12G Converter from Blackmagic Design. Equipped with a 10G Ethernet port for 2110 IP video support and with 12G-SDI input and loop output and HDMI 2.0 connectivity handling resolutions up to UHD 4K, the versatile rackmount device features front-panel controls, and it has a built-in audio monitoring speaker, as well as a headphone jack. Its sleek design takes up only one-third of a 1 RU space, and a USB-C port on the front panel works as an HD webcam port. Reliable performance is further augmented with the low-latency Blackmagic IP10 codec used by the unit.
The 12G-SDI connections re-sync to the common PTP clock, and sync can be output via the built-in BNC connector. The device can also take an incoming sync signal via its BNC reference input, making the unit an essential converter for any studio or live broadcast system. The converter has a low SDI jitter and uses high-quality multi-tap video filters, allowing users to employ longer cables while maintaining the integrity of the signal. Automatic audio delay ensures that audio is always perfectly in sync with video.

Features

2110 IP/12G Up/Down/Cross Conversion
Rackmount Design, Front-Panel Controls
12G-SDI Input, 12G-SDI Loop Out
Re-Syncs SDI Inputs to Common PTP Clock
Low-Latency Blackmagic IP10 Codec
Built-In Audio Monitoring Speaker
BNC Reference Input & Output

Specifications

Category	Item	Details
Video I/O	Input	1x BNC (12G-SDI), 1x HDMI (Unspecified Signal) Female
Video I/O	Output	1x BNC (12G-SDI), 1x HDMI (Unspecified Signal) Female
Video Resolution	SDI Input/Output	3840 x 2160 up to 60 fps
	HDMI Input/Output	3840 x 2160
	RJ45 Input/Output	3840 x 2160 up to 60 fps
Broadcast System Compatibility	-	NTSC, PAL
Wireless	-	No
Inputs/Outputs	Video Input	1x BNC (12G-SDI), 1x HDMI (Unspecified Signal) Female
	Other I/O	1x RJ45 (10 GbE)
	BNC Sync	Input: 1x BNC, Output: 1x BNC
	USB-C	1x USB-C (Unspecified)
	Expansion Slots	No
Latency	-	No
Format Support	Video Resolution	Same as above (SDI/HDMI/RJ45 up to 3840x2160@60fps)
	Embedded Audio	HDMI / LAN (RJ45) / SDI
	Video Standard Compliance	SMPTE ST-2110
	Broadcast System	NTSC, PAL
Hardware	Wireless	No
Display	-	LCD
Power	Power I/O	1x IEC C13 Input, 1x Barrel (12 VDC) Input
General	Rack Form Factor	1 RU
Packaging Info	Package Weight	2.64 lb
Packaging Info	Box Dimensions (LxWxH)	10.4 x 6.9 x 2.7"
