The BG-EXH-70C3 is an 18Gbps HDMI extender that can transmit HDMI and IR control signals up to 230ft(70m) via a single CAT6/6a cable and the uncompressed, long-distance transmission between the transmitter and receiver is achieved with zero-delay. These devices are also HDMI 2.0b and HDCP 2.2 compliant ensuring content is protected. The extenders feature bi-directional IR and power over cable(PoC) meaning only one of the units in the pair needs a power supply while IR blaster and receiver cables can be utilized to control devices on either end of the system simplifying a clean installation.
EDID copy pass-through between the source and display devices help to ensure the best signal quality possible. Video resolution is crystal clear with up to 4K2K @ 60Hz 4:4:4 along with rich colors provided by HDR, HDR10, HDR10+, Dolby Vision, and HLG. The receiving unit (RX) can extract LPCM 5.1, Dolby True HD, and DTS HD Master formats from the ARC connection on a display to its TOSLINK port. The flexible and compact design of the BG-EXH-70C3 allows for a wide range of uses where signal sources may need to be further away from their displays.
Loop-out to view content locally at the transmitter side
Features an EDID copy pass-through function between the source and display devices
Specifically mentions support for HDR, HDR10, HDR10+, Dolby Vision, and HLG
The receiving unit (RX) can extract digital audio from the transmitter via ARC from a display through the TOSLINK port
Supports LPCM 5.1, Dolby True HD, and DTS HD Master audio formats
Supports a transmission extension distance of up to 230ft/70m via a CAT6/6a cable
- The receiving unit (RX) can extract the digital audio from the ARC connection on a display to its TOSLINK port
- EDID copy pass-through
- Audio Formats: LPCM 5.1, Dolby True HD, DTS HD Master, Dolby 5.1, DTS 5.1, PCM 2.0
