Atlona AT-VGA0505-b 5x5 Professional VGA with Audio Matrix Switch

Description

Please NOTE: This listing is for B- Stock item. It means that this unit was refurbished by manufacturer and holds full manufacturer warranty, however it may have scratches, signs of wear and tear or come not in original box.

Atlona 5×5 Professional VGA with Audio Matrix Switch. Model: AT-VGA0505

The Atlona AT- VGA0505 is an 5 input 5 output Commercial VGA with Audio matrix switcher. The AT- VGA0505 is one of the world&39;s advanced matrix switchers. Is is capable of being controlled though RS232 via software included or via a third party control system. Switcher is designed to handle any resolution up to 1920×1200 OR 1080P without any signal degradation.

This device is mainly used in broadcast rooms, multi council-chambers, television teaching rooms, command centers and IT server rooms.

Main Features:

Power-Fail Protection, allows switcher to restore previous settings
RS232 Communication Control Input, allows to control switcher via included advanced Control software or Third Party Control System
IR Remote Control
Inputs: 5 x VGA female15-pin HD, 4 x 1/8&39;&39; (3.5mm) mini Audio
Outputs: 5 x VGA female 15-pin HD, 4 x 1/8&39;&39; (3.5mm) mini Audio
Connectors: 15-pin HD (Could be used for PC resolutions up to UXGA – 1920×1200 or HDTV up to 1080p)
Compatible Formats: RGB, YPrPb or RGBHV
Rack Mountable

Warranty:

3 year manufactures warranty (parts and labor)

Specifications

High Resolution Support: up to 1920x1200@85Hz or even higher
Bandwidth: 40MHz @ (-3dB), fully loaded @1920x1200@60Hz or higher
Cross talk sum: 60dB @10M; -39dB @100M
Switching speed: 200 ns (Max)
Signal type: RGB, YPrPb, RGBHV, RGBS, RGsB, RsGsBs
Audio Connectors: 1/8'' (3.5mm) - mini audio
Temperature: 0C to +65C (32 F to 131 F )
Power Supply: 110V-240V (50-60Hz)
Dimensions (mm): 187mm x 125mm x 43mm (L x W x H)
Dimensions (inch): (7.4''x4.9''x1.7'') (L x W x H)
Unit Weight: 1kg or 2LB
Gross Package Weight: 4LB
