FBT ARCHON 112 12in + 1,4in - 1,4in 70x50 rot Horn 1000Wrms 2-way Passive speaker - AV Pro Supply

Description

ARCHON 112 is a full range/bi-amp 2 ways point source with a crafted birch plywood cabinet.Equipped with custom-designed high-excursion B&C 12″ LF woofers and 1.4″ HF compression drivers, delivers sound pressure levels of up to 129/133 dB SPL in the listening area. This loudspeaker includes rotatable horns for optimal horizontal or vertical dispersion, providing 70° H x 50° V coverage.

Frequency response extends from 50Hz to 18kHz. An optional 100V line transformer (300W) is available. Recommended amplifier power: 1000W RMS. Installation versatility is ensured through 12 integrated M10 threaded rigging points, complemented by flexible mounting hardware and a wide selection of accessories. A rear pocket handle facilitates easy lifting and cabinet installation.

The wide hand made customizations offered made the ARCHON series a cult between the FBT products. Not only different RAL paint colors, but also paint finishes like glossy, matt, textured and more assure the finest camouflage in the environment. The acoustically transparent steel grilles with antidust protection cloth complete this design shaping the perfect speakers for indoor spaces.

The whole ARCHON series is characterized by extremely low distortion, fast responding dynamics and wideband response and it has been designed for applications that require high SPL levels. The rotatable logo badge follows vertical or horizontal installation.

Features

Configuration: 2 way
Low Frequency Woofer: 1 x 12” – 3” VC
High Frequency Driver: 1 x 1.4” – 2.5” VC
Recommended Amplifier: 1000W RMS
Transformer (optional): 100V – 300W
Maximum SPL: 133dB
Material: Baltic birch plywood

Specifications

Configuration	2 way
Recommended amplifier	1000W RMS
Long Term power	500W
Short term power	2000W
Nominal impedance	8 Ohm
Frequency response	50Hz - 18KHz -6dB
Low Frequency woofer	12'' - 3'' coil
High frequency driver	1.4'' - 2.5'' coil
Sensitivity (@1W/1m)	99dB
Maximum SPL cont/peak	129 / 133dB
Dispersion	70° x 50° H x V
Crossover Frequency	1.6 KHz
Recommended HP filter	40hz - 24dB oct
Recommended external filter	FBT DSP Processor
Input connector	4-pin Euroblock / 2 x Speakon
Net Dimension (WxHxD)	365 x 660 x 380 mm (14.3 x 25.9 x 14.9 inch)
Net Weight	25.4 Kg (56 lb)
Color	Black
